WideTEK® 36ART 36 inch Large Format 3D Fine Art Scanner

$46999.00ex. taxes

A wide format contact free scanner for fine art reproductions at 600dpi in formats up to 36 x 87.6 inches.

Available on back-order

TRADE/EDUCATION PRICING AVAILABLE - Call Louise on 01789739207 or CLICK HERE to read more

Get it Thursday, Feb 29, Order in next
Information
SKU: AWIDETEK36 Category:
Guaranteed Safe Checkout

WideTEK 36ART 36in. Large Format 3D Fine Art Scanner

Enhance your scanning capabilities by incorporating the advanced WideTEK 36ART 36-inch Scanner into your workflow. This state-of-the-art solution is specifically engineered to provide scans of exceptional detail, remarkable speed, and unmatched color accuracy. Whether you operate a small business or a large enterprise, this cutting-edge scanner utilises CCD (Charge Couple Device) scanning technology, combined with user-friendly features and an intuitive interface, guaranteeing optimal results for all your scanning requirements.

Product Brochure – DOWNLOAD THE WideTEK 36ART Flatbed 3D Scanner Brochure

Installation, Configuration, Delivery & Training

Unlike our competitors we offer a full configuration, installation, delivery and training service and have trained individuals able to provide telephone support to customers. These options can be tailored to suit each individual customer dependent upon their needs. PermaJet are a registered distributor for Image Access and the only company in the UK specialising in their Fine Art and Photography reproduction scanners.



Core Features

Contactless Scanning up to 36 x 87.6 inches
The WideTEK® 36ART scanner offers contactless scanning, perfect for delicate artworks such as pastels or charcoal. The camera’s are fixed and the table moves beneath them offering scans up of up 36 x 60inches, with the optional table extension this increases to 36 x 87.6inches.

High Resolution Scanning
This model takes advantage of CCD technology, utilising a light source, mirrors, lens and image sensors to deliver high resolution scans up to 600 x 600dpi optical resolution. The scanner is able to scan images in a multitude of formats including TIFF, JPEG and PDF.

Variable Focus
The design of the WideTEK 36ART allows the camera box within the housing to move up and down meaning the focal point of the 3 camera’s can be adjusted. This is especially useful for highly textured pieces of art. It benefits from a maximum scan height of 4 inches.

Anti-Reflective Setting
The anti reflective setting allows delicate artwork to be scanned through glass, meaning artwork does not have to be removed from its original frame in order to be reproduced.

Rapid Scan Time
A colour, 300dpi scan can be captured at a rate of 42.4 mm/s (21.1 mm/s for a 600dpi scan) and when utilising the 3D feature a colour, 300dpi scan can be achieve a capture rate of 21.1 mm/s (10.7 mm/s for a 600dpi scan). As the scanner utilises 2 LED bars there is no warm up time.

2D & 3D Scanning
The revolutionary 3D scanning mode opens many new opportunities in Fine Art Printing, allowing users to capture paper surface textures, art materials such as acrylic and oil and any other textured pieces.The WideTEK 36ART has two LED lamps, twice as many as the competition.

With the new diffusors, these lamps produce an extremely homogeneous illumination which eliminates all unwanted shadows caused by folds, wrinkles and other distortions of the scanned object.

User Friendly Interface
The user friendly interface is accessed through a web browser meaning that it’s suitable for both PC and Mac users. Alternatively there is an option to scan straight to a USB drive or utilise the built in 15inch colour touchscreen display.

Unmatched Colour Accuracy
The scanner handles 36-bit colour meaning it’s capable of capturing 68 billion colours, after gamma, white and black point correction and other image operations are performed on the 36-bit data, the best 24-bits are outputted. This ensures scans benefit from low noise and rapid transfer whilst ensuring quality is not lost. Whilst extremely colour accurate out of the box, the scanner can be ICC profiled in either Adobe RGB or sRGB colour spaces and produces print ready scans without the need for image manipulation or post processing.



Warranty

All scanners come with a free 1 year RTB warranty with a full parts and labour warranty is also available for up to 5 years.



Sample Scans – Click to View (Long Loading Time)





Scanner Enquiry






    Functions & Features

    Functions
    Scans fine art or other material 914 x 1524 mm / 36 x 60 inches wide or 914 x 2224 mm / 36 x 87.6 inches wide, with optional scan table extension
    Exceeds FADGI *** guidelines, ISO 19264-1
    Maximum scan height of 100 mm / 4 inches
    Document thickness of 200 mm / 8 inches (E.g. Canvas up to max. 100 mm in a frame up to 200 mm thickness)
    Fastest 3D texture color scanning at 21.1 mm/s / 0.83 inch/s @ 300dpi
    600 x 600 dpi optical resolution
    On the fly rotation while scanning facilitates postprocessing
    Face up scanning (no more “blind”scanning)
    Real time display of scanned images, modify images without rescanning
    Standalone device with its own integrated PC
    Scan2USB — Walk up Scanning to any USB device
    Scan2Print — Copy to networked printers or hot folders
    Output formats: PDF, PDF/A, JPEG, TIFF, PNM, multipage PDF and TIFF, DICOM and many more
    Scan2Network — Output to network resources, SMB, FTP


    Functions
    Contact-free scanning of fragile material or even wet artworkScan table can be moved manually or motorized
    Dual LED lamps with integrated natural light diffusor, no warm up, IR/UV fre
    Large 15 inch color touchscreen for simplified operation
    Single path texture scanning, patent pending stitching
    Motorized focus adjustment up to 4 inches
    User interface configurable in your language
    Virus resistant Linux OS
    OS independent, runs with Windows 7, 8, 10, Linux, Mac
    ScanWizard uses any browser: IE, Safari, Chrome, Firefox
    Integrated walk up scanning software
    Easy installation via Scan2Net® Technology
    Remote maintenance and troubleshooting
    Firmware updates via web interface
    Dust-free camera technology
    Full Coverage Warranty – Up to 5 years subscription for full coverage warranty package and free spare parts

    Technical Data - WideTEK 36ART

    Technical Data

    Document
    Maximum Document Size – 914 x 1524 mm (36 x 60 inches), optional Scan table extension up to 914 x 2224 mm (36 x 87,6 inches
    Maximum Scan Heights – 100 mm (4 inch)
    Document Thickness – 200 mm (8 inch) E.g. Canvas up to max. 100 mm in a frame up to 200 mm thickness
    Autoformat Size Recognition – Yes
    DIN Format – DIN A5 – DIN A0
    ANSI Format – Legal, US E
    User Defined Format – Yes

    Output
    Optical Resolution – 600 x 600 dpi
    Pixel Dimension – 9.3 x 9.3 µm
    Scan Speed Colour – 300 dpi – 42.2 mm/s (1.66 inch/s), 600 dpi – 21.1 mm/s (0.83 inch/s)
    Scan Speed Colour 3D – 300 dpi – 21.1 mm/s (0.83 inch/s), 600 dpi – 10.7 mm/s (0.42 inch/s)
    Color Depth – 46 bit color, 16 bit grayscale
    Scan Output – 24 bit color, 8 bit colour indexed, bitonal, enhanced halftone
    File Formats – Multipage PDF (PDF/A) and TIFF, JPEG, JPEG 2000, PNM, PNG, BMP, TIFF (Raw, G3, G4, LZW, JPEG), AutoCAD DWF, JBIG, DjVu, DICOM, PCX, Postscript, EPS, Raw data
    Quality – Exceeds FADGI *** guidelines, ISO 19264-1

    Technical Specification
    Computer – 64 bit Linux, Intel i3, quad core processor, 8 Gigabyte RAM, 320GB HDD for extra large jobs
    Touchscreen – 15 inch. colour touchscreen
    USB Port – 1 USB Port 3.0
    Interface – 1 GBit Fast Ethernet with TCP/IP based Scan2Net(R) interface
    Camera – 3 x Tri-Color CCD cameras, 67,500 pixels, encapsulated and dust-proof
    Light Source – Dual LED lamps with 54 white LEDs each, natural light diffusor, no IR/UV emission
    Lamp Life Time – 50,000 h (typ.)

    Dimensions
    Dimensions Scanner (H x W x D) – With runway: 1380 x 3275 x 1280 mm (54.3 x 128.9 x 50.4 inches), without runway: 1380 x 690 x 1280 mm (54.3 x 27.2 x 50.4 inches), Scan table: 1000 x 2100 mm (39.4 x 82.7 inches)
    Weight Scanner – 200kg (440lbs.)
    Weight Scan Table – 22.5kg (50lbs.)

    Electrical Specification
    Electrical Connection – 100-240 V AC, 47 – 63 Hz (external power supply, complies with ECO standard CEC level V)
    Power Consumption – ≤ 0.5W (Sleep) / 5.2W (Standby) /<50W (Ready to Scan, 55W (Scanning)

    Ambient Conditions
    Operating Temp – 5 to 40 °C, 40 to 105 °F
    Rel Humidity – 20 to 80 % (non-condensing)
    Noise – < 35 dB(A) (Scanning) / < 25 dB(A) (Standby)

    Weight500 kg
